Proton ECOMATIC PRO User Manual

34
All wires have to be pressed by cord end terminals.
Dimensions of the wires have to be chosen by an installer.
Minimal wire section is 1 mm².
Use shielded wires.
Close the cover before start-up.
8. WIRING DIAGRAM
RISK OF ELECTRICAL SHOCK. Disconnect power supply
before making electrical connection of RTS 40.
1312111098765432
V
LN
AC230
Heat 1 Heat 2
NO
NTC
Med LoHi
1
A/+ B/-
RS485
Fan
V
Door
switch
N
WARNING!
RTS 40 programmable controller RTS 40 programmable controller
