SL mini and SLR mini-i4 Series Speed and Length Gauges Instruction Manual - issue 3h
Pull-down
Pull-up
+15V
DGND
5.1kΩ
+15V
DGND
5.1kΩ
820Ω
820Ω
From PLC
Active High
Logic Output
