Proton SL mini Series - Output Parameters

Page 83 of 85
SL mini and SLR mini-i4 Series Speed and Length Gauges Instruction Manual - issue 3h
OUTPUT PARAMETERS
1 DW word = 2 bytes
DW
Bit
Comments
Units
Range/Remark
DW0
0
Measurement mode
0=Normal;1=Batch
1
Resolution of length output
0=length 0.0001;1=length 0.1
2
Speed reponse for pulse and
analogue output
0=Instant;1=Averaged
3
4
5
6
7
8
Measured length > Preset1
1=>Preset
9
Measured length > Preset2
1=>Preset
10
11
Laser Status
1= ON;0=OFF
12
Speed reading valid
1=Valid;0=Invalid
13
Object detected
1=Object detected;0=No object
14
Good reading status
1=Lower than threshold;0=OK
15
DW1
0
Gauge OK
1=OK;0=Failed
1
Laser temperature too high
1=Too high;0=OK
2
Laser temperature too low
1=Too low;0=OK
3
Case temperature too high
1=Too high;0=OK
4
Case temperature too low
1=Too low;0=OK
5
Light reflection too strong
1=Too high;0=OK
6
Gauge too hot
1=Too hot;0=OK
7
8
DW2
Averaged speed
1=0.001m/min{ft/min}
0~±2
31
DW3
DW4
Instant speed
DW5
DW6
Total length
1=0.0001/1=0.1m{ft}{yds
}
0~±2
31
DW7
DW8
Batch length
DW9
DW10
Last length before reset
0~2
31
DW11
DW12
Reel number
1=1
0~2
32
DW13
DW14
Batch number
1=1
0~65535
DW15
Good reading
1=1%
0~100
