SL mini and SLR mini-i4 Series Speed and Length Gauges Instruction Manual - issue 3h
SPECIFICATIONS
MODEL-SPECIFIC SPECIFICATIONS
Specification
Unidirectional – SL mini
Bidirectional – SLR mini
Units
1220
3060
1220
3060
Minimum speed
0.15
0.25
0
0
m/min
Maximum speed
2000
3000
±2000
±3 000
m/min
Nominal stand-off distance
120
300
120
300
mm
Depth of field
20
60
20
60
mm
COMMON SPECIFICATIONS
Specification
Minimum
Typical
Maximum
Units
Accuracy
-0.05
0.05
%
Repeatability
-0.02
0.02
%
Acceleration
500
m/s
2
Measurement update time
40
µs
Laser beam diameter
3
mm
Laser classification
3B
-
Operating temperature
+5
+40
°C
Environmental protection
IP67
-
Power supply voltage
18
24
30
VDC
Power consumption
15
W
Length
142
mm
Width
104
mm
Height
53
mm
Measurement display
Integrated backlit LCD
Pulse outputs
3× RS-422 compliant differential pair outputs with
maximum pulse rate 2 MHz (cable length dependent),
end-user configurable as:
6× independent pulse outputs
3× quadrature output
Laser safety
Laser enable input
Open shutter input
Shutter status output
