SL mini and SLR mini-i4 Series Speed and Length Gauges Instruction Manual - issue 3h
3× Logic inputs (end-user configurable
functions)
Reverse Direction
Length Hold
Reset
Speed Hold
End of Reel
Display Hold
2× Logic outputs (end-user configurable
functions)
Gauge OK
Gauge too hot
Good reading
Object detected
Preset length 1 / Batch length reached
Preset length 2 / Batch number reached
Gauge measuring speed
Standard communications interfaces
RS-232*
CANbus**
Ethernet TCP/IP (Modbus protocol), WIFI, OPC UA
PROFIBUS
PROFINET
EtherNet/IP
*An optional RS-232-to-USB converter cable is available for connection to USB equipped computers.
**CAN-bus protocol is proprietary and reserved for connection to other Proton Products equipment
such as a CDI4 interface display unit.
