SL mini and SLR mini-i4 Series Speed and Length Gauges Instruction Manual - issue 3h
DW
Bit
Comments
Unit
Range/Remark
Default
value
15
DW19
Logic input
0
LIN1 function
0=Direction (count down);
1=Length hold;
2=Display hold;
3=Speed hold;
4=Total length reset;
5=Batch length reset/End of
reel;
6=None
4
1
2
3
LIN2 function
1
4
5
6
LIN3 function
2
7
8
9
LIN1 polarity
0=Active low;
1=Active high
0
10
LIN2 polarity
11
LIN3 polarity
12
Speed direction (available only when
no logic input for direction)
0=Up/Normal;
1=Down/Invert
0
DW20
Logic output function
0
LOP 1 function
0=Gauge OK;
1=Gauge measuring speed;
2=Preset length1 / Batch length;
3=Preset length 2 / Batch
number;
4=Good reading;
5=Object detected
6=Gauge too hot;
13=User 1;14=User 2;15=User
3
0
1
2
3
4
LOP 2 function
2
5
6
7
8
LOP 3 function
3
9
10
11
12
13
User I/P 1
0=OPEN;1=CLOSE
0
14
User I/P 2
0=OPEN;1=CLOSE
15
User I/P 3
0=OPEN;1=CLOSE
DW21
Full scale for analogue O/P
1=1m/min{ft/min}
0~65535
1000
DW22
Minimum speed limit
1=0.01m/min{ft/min}
0~65535
0
DW23
DW24
Length offset
1=0.0001m{ft}{yds}
-2
31
~+(2
31
-1)
0
DW25
DW26
Averaging time
1=1ms
1~5000
1000
DW27
Hold time after speed drop out
1=1ms
1~5000
100
DW28
Closure time for logic output in batch
mode
1=1ms
1~5000
500
DW29
Good reading threshold for logic
output
1=1%
60%
