1 Technical data
* Speed specifications with fully charged bat-
tery pack.
** The maximum speed is reduced in the
lower torque stages.
2Symbols
Cordless impact drill PDC 18-4 Compact
Motor voltage 18 V
Idling speed* 1st gear 0 - 400 rpm
2nd gear 0 - 850 rpm
3rd gear 0 - 1850 rpm
4th gear 0 - 3800 rpm
Max. torque
soft/ hard material 28/ 50 Nm
Adjustable torque** 1st gear 0,75 - 12 Nm
2nd gear 0,6 - 7,5 Nm
3rd gear 0,55 - 5 Nm
4th gear 0,5 - 2,7 Nm
Chuck clamping range 1,5 - 13 mm
Drill diameter max.
Wood/ Metal 50/ 12 mm
Weight 1,8 kg
Charger BCL 3
Mains voltage (input) 220 - 240 V ~
Mains frequency 50/60 Hz
Charging voltage (output) 10.8 - 18 V=
Rapid charging max. 3 A
Conservation charging, intermittent (NiCd, NiMH) approx. 0.06 A
Charging times for
Li-ion 1.5 Ah, 80 %/100 % approx. 25/35 min.
Permitted operating temperature range -5 °C to + 45 °C
Temperature monitoring with NTC resistor
Battery pack BP 18 1,5 Ah LiIon
Voltage 18 V
Capacity 1,5 Ah
Weight 0,4 kg
Warning of general danger
Risk of electric shock
Read the Operating Instructions/
Notes!
Wear ear protection.
Wear protective gloves.
Wear protective goggles.
