17
4 Control Elements
[1-1] Extraction connector
[1-2] Handles
[1-3] Switches
[1-4] Safety button
[1-5] Suction hood/base plate
[1-6] Vent openings
[1-7] Speed selection thumbwheel
[1-8] Longing screw
[1-9] Locking button
[1-10] Lifting eye for balancer
[1-11] Material removal depth adjustment
lever
[2-1] Wrench arm
[2-2] Pipe socket wrench a/f 10/13
[2-3] Clamping nut
[2-4] Tool head
[2-5] Spindle
[2-6] Spring
[3-1] Extractor
[4-1] Stud
[4-2] Inner ring
[4-3] Bearing pin
[4-4] Grinding wheel
[4-5] Shim
[4-6] Bush
[5-1] Screw
[5-2] Grinding disc
[5-3] Grinding head
[6-1] Screw
[6-2] Slide plate
[6-3] Lower brush
[6-4] Spring
[6-5] Bolt
[6-6] Suction hood bolt
[7-1] Front brush
[7-2] Screw
[7-3] Guard panel
Accessories
Cutter head
“split-form” teeth
SZ-RGP 150
Cutter head
“fl at-form” teeth
FZ-RGP 150
Grinding head DIA HARD-RGP 150
Grinding head DIA ABRASIV-RGP 150
Grinding head DIA UNI-RGP 150
Grinding head HW-RGP 150
Grinding wheels
“split-form” teeth
HW-SZ 35
Grinding wheels
“fl at-form” teeth
HW-FZ 35
Diamond disc DIA-HARD 150
Diamond disc DIA-ABRASIV 150
Diamond disc DIA UNI 150
Carbide disc HW 150/SC
Surface guidance
system
BG-RGP 150
Balancer BR-RGP 150
Socket wrench FK-SW13-RGP 150
Guard BC-RGP 150
Extractor RT-RGP 150
Not all of the accessories illustrated or de-
scribed are included as standard delivery.
5 Notes on Safety
Prevention
DANGER
5.1 General Safety Instructions
- Before using the machine, carefully read
all safety instructions and the Operating
Instructions.
- Keep all of the attached documents and
pass on the documentation if the ma-
chine changes ownership.
5.2 Safety instructions for all
work activities
Safety warnings common for the
following works: grinding, surface
grinding or grinding with wire brush:
a) This electromechanical tool is de-
signed to be used as a surface grinder
or a cutter with a cutter head. Read
all safety warnings, instructions, il-
lustrations and specifi cations intend-
ed for this electromechanical tool.
Failing to meet all the below specifi ed
instructions may lead to injury by electric
current, fi re and/or serious injury.
b) This tool is not recommended for pol-
ishing, cutting or abrasive cutting.
Execution of works this tool is not de-
signed for may create a risk and cause
injury of a person.
c) Do not use accessories which is not
explicitly designed and recommended
by the tool manufacturer. The fact that
the accessories an be attached to your tool
does not guarantee its safe operation.
