Technical Specs
PWHFi / iW
SINGLE SPEED
3 Years Warranty
Code PWHF1000i PWHF1000iW PWHF1000u PWHF1000uW
Capacity
Lb
2200 2200 2200 2200
Lifting Speed
Ft/Min
8 ft / 2.5 m 8 ft / 2.5 m 8 ft / 2.5 m 8 ft / 2.5 m
Lifting Height
Ft
20 ft / 6 m 20 ft / 6 m 20 ft / 6 m 20 ft / 6 m
Motor Power
kW
0.65 kW 0.65 kW 0.65 kW 0.65 kW
Voltage
V
220~240V 50/60Hz 1 Phase
Motor Speed
RPM
4 4 8 8
Insulation Grade
Grade
F
Chain Type
Grade
G80
Chain Dimensions
mm
8x24 mm 8x24 mm 8x24 mm
Chain Falls
U
2
Chain Length
Ft
40 ft / 12 m
Operation Temperature
F°
Operating Humidity
%
<85%
Noise Level
dB
7P dB
Control Voltage
V
24
Weight
Lb
150 160 171 154
Duty Class
FEM/ISO
H2/M3/1Bm/Class B
Standards ASME HST-1 , ASME B30.16 , EN14492-2 , EN60204-32
