Installation
| 32 | Version 1.0
TROUBLESHOOTING
After unpacking, please careful check over the appearance of the cable, gear box and motor shell. Check the
quantity of the bellowing items as well. Every set of our hoist should including the bellowing standard spare
parts:
1. 2 directions wiring diagram for single speed
2. 4 directions wiring diagram for single speed
3. 6 directions wiring diagram for single speed
4. 2 directions wiring diagram for double speeds
5. 4 directions wiring diagram for double speeds
6. 6 directions wiring diagram for double speeds
7. Wiring diagram for single phase motor
The above mentioned wiring diagrams above are only for reference, user should take the one inside the electric
box as the proper one.
The electric specications can be made according to the follows:
