ORiNOCO
®
802.11n & 802.11ac Access Points - Hardware Installation Guide 41
3.3 ORiNOCO
®
AP-9100
Category Specification
Power
Requirements
Power Adapter: 12V/1.25A
Power over Ethernet (PoE) (optional): 48V / Any 802.3af compliant Gigabit PoE
Radio Module
Dual Radio Access Point, 3x3 MIMO per radio
Radio1: IEEE 802.11a/n/ac (5 GHz)
Radio2: IEEE 802.11b/g/n(2.4 GHz)
Refer Device Operational Modes.
Wireless Protocol
802.11b/g/n
802.11ac
Frequency
5.150 GHz – 5.850 GHz
2.400 GHz – 2.484 GHz
* Subject to Individual Country Regulations
Channel
bandwidth
20MHz and 40MHz for 802.11b/g/n
20MHz, 40MHz and 80 MHz for 802.11ac
Modulation
• BPSK, QPSK, 16-QAM, 64-QAM and 256-QAM
– With data rates up to 450 Mbps for 802.11b/g/n (3x3 MIMO)
– With data rates up to 1300 Mbps for 802.11a/n/ac (3x3 MIMO)
– With data rates up to 866.7 Mbps for 802.11ac (2x2 MIMO)
Device Interface
Ethernet: Auto-sensing 10/100/1000BASE-T Ethernet
LED Indicators
Refer Step 4: View LEDs
Antennas
6 Modular High Efficiency built-in PIFA Antennas with a peak gain of:
– 4.46dBi for (2.400 to 2.484) GHz frequency.
– 5.0dBi for (5.150 to 5.850) GHz frequency.
Network
Architecture Type
Infrastructure
: The operational mode ‘g/n’ is backward compatible to mode ‘b’.
