VIII. SPECIFICATIONS
SubSeries 1
SubSeries 5i SubSeries 6i
FREQUENCY RANGE (Anechoic Chamber)
Response
On Axis @ O· ±3dB
36-150Hz 30-150Hz 29-150Hz
LF Cutoff -10dB
32Hz
27Hz 26Hz
AMPLIFIER POWER-INTERNAL (RMS, Clipping <10% Time)
Continuous 110 Watts 150 Watts 225 Watts
Dynamic 140 Watts 225 Watts 325 Watts
Peak
280 Watts 450 Watts 650 Watts
Type
Class AB Class H/BASH Class H/BASH
Discrete MOSFET
Discrete MOSFET Discrete MOSFET
Output Devices Output Devices Output Devices
ACOUSTIC DESIGN
Woofer 8" (203mm)
10" (250mm) 12" (300mm)
Polypropylene Cone Polypropylene Cone
Polypropylene Cone
Rubber Surround Rubber Surround Rubber Surround
1)12" (38mm) Voice Coil 11/;>" (38mm) Voice Coil 2" (50mm) Voice-Coil
28 oz (794g) Magnet
28 oz (794g) Mag net 53 oz (1503g) Magnet
+20 oz (567g) Shielding Magnet +28 oz (794g) Shielding Magnet
Crossover Variable 50Hz-150Hz Variable 50Hz-150Hz
Variable 50Hz-150Hz, LR4
24dB/octave Linkwitz-Riley
24dB/octave Linkwitz-Riley 24dB/octave Linkwitz-Riley
Low Pass Filter Low Pass Fi Iter Low Pass Filter
Internal Volume 0.68 cu It (19.3 liter) 1.01 cu II (28.6 liter)
2.38 cu It (67 liter)
Design Type Bass Reflex Bass Reflex
Bass Reflex
1 x 8" Front Duct (25mm x 203mm) 2 x 2" Front Porls (508mm)
2x 2 5/8" (66.7mm) Front Ports
Radiused Externally
Radiused Internally and Externally Radiused Internally and Externally
Video Shielded
Video Shielded
SIZE
WEIGHT
Net
Shipping
FINISH
CONNECTIONS
FEATURES
(W x Hx D)
9 5/8 x 13 1/4 x 14 1/2"
244 x 337 x 368mm
Plus 1" (25mm) Feet
23.5 Ib (10.8kg)/each
27.5 Ib (12.6kg)/each
Black Textured, Sienna or
Maple Vinyl Veneer
Low/Line Level/LFE Input
High/Speaker Level Input
Front Mounted Volume
and Crossover.
Phase, Crossover Bypass and
On-Standby/Oil
5-way Binding Posts and
Gold-plated RCAs
123/8 x 16 112 x 14 7/8"
314 x 419 x 378mm
Plus 7/8" (22mm) Feet
31 Ib (14kg)/each
34 Ib (16kg)/each
Black Ash Vinyl
Low/Line Level/LFE Input
High/Speaker Level Input
and Output
Front Mounted Volume
and Crossover.
Phase, Crossover Bypass and
On-Standby/Oil
5-way Binding Posts and
Gold-plated RCAs
15 x 19 7/8 x 19 1/4"
381 x 505 x 489mm
Plus 1" (25mm) Feet
461b (20.9kg)/each
541b (24.6kg)/each
Black Ash Vinyl
Low/line Level/lFE Input and Output
High/Speaker Level Input
and Output
80 Hz High Pass Filter
12 dB/octave Butterworth
High Level High Pass
6 dB/octave Filter
Front Mounted Volume
and Crossover.
Phase,
On-Standby/Oil
5-way Binding Posts and
Gold-plated RCAs
Feet with Adjustable Spikes
& Rubber Levelers
120V,60Hz 220-240,50/60Hz 120V,60Hz 220-240V, 50/60Hz
1.6A, 250V TO.8A, 250V, 2.0A, 250V T1.0A, 250V,
5mm x 20mm 5mm x 20mm
*Manufactured by Littlefuse Type 313 or Equivalent
120V, 60Hz 220-240V, 50/60Hz
2.5A, 250V T1.25A, 250V,
5mm x 20mm
POWER
Input
Fuse
C€
~: or
ui"106416
C€
~, or
NRTUC
ui"Ui.
C€
