Puloon LCDM-2000 - H;W Constitution; 2-1. Main Board Layout

PULOON Technology Inc.
LCDM-2000
2. H/W Constitution
24V  5V Conversion Circuit
BLDC MOTOR
Solenoid,Clutch
CPU,ROM,RAM
RS232 Communication Circuit
RVDT Circuit
DIP SWITCH
SEGEMENT
SENSOR Circuit
