PULOON Technology Inc.
LCDM-2000
1-4. Feed Module Structure
Feed Module consists of auto cash feeder part , double feeding detection part ,
diverting mechanism part , cash delivery part and Feature is shown below.
Diverter
Pick-up Roller(Upper)
Feed motor
One-way Roller(Lower)
Note Path
(Delivery)
Pick-up Roller(Lower)
One-way Roller(Upper)
Double Detect Roller
(Lower)
Double Detect Roller
(Upper)
