LCDM-2000
1-3-3. Cash Cassette Body
Cash cassette body consists of frame,pushing plate & stopper.
Pushing plate moves bill to “Pick-up roller” along with side- slot by power of spring.
Hook & Axle of stopper is in the rear of “pushing plate & frame” respectively.
Stopper is automatically closed & opened by backing pushing plate and
opening door respectively.
1-3-1. Capacity & Currency of Cash cassette
100mm
Width
162mm78mm62mm
WidthHeightHeight
MaximumMinimum
Capacity is approximately 123 mm( I.E about 1,000 bills can be
stacked base on new note) & usable currency dimension is as below diagram
1-3-2. Cash cassette door
Cash cassette door is magnetically closed & can be opened
If pushed label direction without special locker
1-3-4. Cash Cassette Base
When cash cassette is inserted, the part of transporting open automatically
by the function of Cash cassette base which is located in the part
of transporting part.
