Pulsar ACCOLADE 2 LRF Quick Start Guide

ENGLISH
Stream Vision App
Download the Stream Vision app to stream the image via Wi-Fi from the display
of your Accolade LRF to a smartphone or tablet. Detailed instructions are
available on the Internet at: www.pulsar-vision.com.
Specications
MODEL ACCOLADE 2 LRF XP50
SKU 77410
MICROBOLOMETER
Type uncooled
Resolution, pixels 640x480
Frame rate, Hz 50
Pixel size, microns 17
OPTICAL SPECIFICATIONS
Magnication ratio, x 2.5 - 20
Lens F50 mm,F/1.2
Field of view angle, (horizontal), deg/ m@100m 12.4/ 21.8
Eyepiece focusing range, diopters ±5
Detection distance for deer-sized objects, m/ y 1800 / 1968.5
DISPLAY
Type AMOLED
Resolution, pixels 640x480
OPERATIONAL CHARACTERISTICS
Power supply, V 3.0 - 4.2
Battery Type/ Capacity/ Nominal output voltage Li-ion Battery Pack IPS7 /
6400 mAh / DC 3.7 V
External power supply 5 V
Battery run time* at t=22 °C, h 9
Protection degree, IP code (IEC60529), with battery
installed
IPX7
Operating temperature range, °C (°F) -25…+50 (-13…+122)
Dimensions, mm/ inch 164 х 130 х 64/ 6,46 х 5,12 х 2,52
Weight without battery, kg/ oz 0.6 / 21.16
4

Pulsar ACCOLADE 2 LRF Specifications

General

Objective Lens Diameter	50 mm
Detection Range	1800 m
Sensor Resolution	640x480 pixels
Display Type	AMOLED
Pixel Pitch	17 µm
Frame Rate	50 Hz
Laser Rangefinder Range	1000 m
Protection level	IPX7
Dimensions	164x130x64 mm
Waterproof	Yes
Fogproof	Yes
Weight	0.7 kg
Display Resolution	640x480 pixels
Operating Temperature	-25 … +50 °C
Battery Type	Li-Ion Battery Pack
