Mode М (manual)
- Close the lens cover, press briefly the ON/OFF (1) button.
- Open the lens cover.
Mode SA (semi-automatic)
- Press briefly the ON/OFF (1) button to calibrate.
- You do not need to close the lens cover (the sensor is closed with the
internal shutter automatically).
Mode А (automatic)
- The device calibrates by itself according to the software algorithm
- In the automatic mode the user can calibrate the sensor with the
ON/OFF button.
You do not need to close the lens cover (the sensor is closed with the
internal shutter automatically).
10
The device allows you to quickly increase the basic magnification
(please refer to the line in the specifications table) by «Digital zoom»
two times or four times 8 times XP models). To operate (XQ models) or (
the discrete digital zoom, press successively the button. DOWN (5)
The digital zoom will not be saved after the device is re-started.
QUICK MENU FUNCTIONS
11
To toggle between the functions below, press successively the M
button.
Enter the menu with a short press of the М (3) button.
For example: the device's basic magnification is 3. , continuous 1х
digital zoom value 1.7. Actual magnification is 5. (3. *1.7).х 2х 1
Notes.
– actual magnification is the product of the basic magnification value
and continuous digital zoom value.
– display brightness and contrast settings are saved in the memory
when the unit is turned off.
- To exit quick menu, press and hold down the M button or wait 5 sec
for automatic exit.
MAIN MENU FUNCTIONS
12
Select the desired mode in the menu option «CALIBRATION»
Digital zoom UP/ DOWN– press the buttons to change digital
zoom from 1.0x to 4.0x (or 8.0x in XP models). digital Incremental
zoom is in 0.1x increments.
The stadiametric rangefinder UP/ DOWN — press the buttons
to to an object being ranged (please refer to measure distance
respective section for more details).
Basic mode – it allows you to select one of the three
modes as the basic one for the user mode.
DISCRETE DIGITAL ZOOM
The Quick menu allows change of basic settings (display brightness and
contrast, inceremental digital zoom and stadiametric rangefinder).
Contrast – press the UP/ DOWN buttons to change display
contrast from 00 to 20.
Brightness – press the UP(2)/DOWN(5) buttons to change
display brightness from 00 to 20.
Press the UP(2)/DOWN(5) buttons to switch between the menu
options.
Upon exit from the menu the cursor location is memorized only for
the duration of the working session (i.e. until the unit is turned off).
Upon restarting the device and entering the menu the cursor will be
located on the first menu option.
Enter a menu option with a short press of the М button.
Exit the menu with a long press of the М button.
Enter the main menu with a long press of the М (3) button.
Automatic exit takes place in 10 sec of inactivity (buttons are not
pressed).
Menu navigation is cyclical: as soon as the last menu option of the
first tab is reached, first menu option of the second tab starts.
10
9
