Pulsar Axion 2 LRF User Manual

Specifications
XQ35
Model XQ35
SKU 77479
Microbolometer

Type uncooled
Resolution, Pixels 384x288
Pixel Pitch, µm 17
Frame Rate, Hz 50
Optical Characteristics

Optical Magnification, x 2
Smooth Digital Zoom 2-8
Digital Zoom, x x1, x2, x4
Lens Focus, mm 35
Relative Aperture, D/f' 1.0
Minimum Focus Distance, m/y 5 / 5.47
Eye Relief Diameter, mm/inch 4 / 0.16
Angular Field of View
(Horizontal x Vertical), degree
10.7х8
Linear Field of View, m at 100
m
18.2
Eyepiece Focus Range, Dioptre +4 / -5
Detection Distance for Deer-
Sized Objects, m/y
1300 / 1422

Pulsar Axion 2 LRF Specifications

General

Frame Rate	50 Hz
Laser Rangefinder	Yes
Wavelength of Laser Rangefinder	905 nm
Display Type	AMOLED
Photo/Video Recording	Yes
Built-in Memory	16 GB
Wi-Fi	Yes
Stream Vision 2	Yes
Waterproof Rating	IPX7
Range of Laser Rangefinder	up to 1000 m
Display Resolution	1024x768 px
Power Supply	Built-in battery
External Power Supply	USB Type-C
Operating Temperature	-25°C to +50°C
