To turn on and off the PiP function see the PiP Mode section.
Press and hold the UP (5) button to change the magnification ratio in
the PiPwindow.
The zoomed image is displayed in a dedicated window, while the image
in the rest of the screen is displayed at base magnification (2x).
When the PiP is turned on you can control both the discrete and smooth
digital zoom. In this case the zoom value changes only take place in the
dedicated window.
When the PiP function is turned off, the screen will display at the
magnification that was set in PiPmode.

Pulsar Axion 2 LRF Specifications

General

Frame Rate	50 Hz
Laser Rangefinder	Yes
Wavelength of Laser Rangefinder	905 nm
Display Type	AMOLED
Photo/Video Recording	Yes
Built-in Memory	16 GB
Wi-Fi	Yes
Stream Vision 2	Yes
Waterproof Rating	IPX7
Range of Laser Rangefinder	up to 1000 m
Display Resolution	1024x768 px
Power Supply	Built-in battery
External Power Supply	USB Type-C
Operating Temperature	-25°C to +50°C
