DMX Address: n
Receiving:
(where n=1 to 512)
NO SIGNAL or DMX or PMX or ERROR
LCD DISPLAY:
DMX Address:
ChromaZone Mode:
Channels per Fixture:
Fixture number:
Chase patterns:
A 2 line, 16 character per line, LCD display is
used to set up, and indicate the status of the product.
At switch on, the display shows:
ress the (Up) or (Down) keys to cycle through the Menu
Options (see ).
Press the key on the to change the settings.
Program Mode self cancels after ~30 seconds if no keys
have been pressed.
if, at any time, the display shows , then
there is a problem with the DMX signal. It could be wiring,
termination or poorly implemented DMX.
depending on the operating mode, a block of
3, 6, 9, 10, 36, 42 or 46 channels is received from the DMX signal
see . The is the
number of the first channel in the block.
To set the required , press the or keys on the
until the display shows
Press the key on the , then set the start address
using the or keys. These keys repeat if held down.
When the required number shows in the display,
press the key to save changes or key to restore
the previous settings.
the text (NO SIGNAL / PMX / DMX / ERROR) in
the display is for information only.
The options are 3, 6, 9, 10, 36, 42 and
46 channel modes see .
To set the required , press the or keys on the until
the display shows :
Press the key on the , then select the required
mode using the or keys.d
When the required shows in the display,
press the key to save changes or key to restore
the previous settings.
the CZ12 uses 36 channels per
fixture and the CZ6 uses 18 channels per fixture.
To view the number of , press the or
keys on the until the display shows
Pressing the key on the , followed by the or
keys will have no effect.
Press the key to save changes or key to return
to the previous menu.
36 divided by the
(shown above) gives the number of fixtures available from the
data block.
ACZ12 can only be 1 of 1 fixture.
A CZ6 may therefore be either 1 (or 2) of 2 fixtures.
To set the required , press the or keys on
the until the display shows
Press the key on the , then select the required
number using the or keys.
When the required shows in the display, press
the key to save changes or key to restore the
previous settings.
may be .
To set the required , press the or keys on the
until the display shows :
Press the key on the , then select
using the or keys.
When the required shows in the
display, press the key to save changes or key to
restore the previous settings.
P
LCD Display Sheet
Channel Assignments Tables
Channel Assignments Tables
6 or 12 way
6 or 12 way
X UIM
Note:
Note: Receiving: ERROR
DMX Address
DMX Address
UIM DMXAddress:
X (change) UIM
DMX Address
(Yes) X (Back)
Note: Receiving:
Mode UIM
ChromaZone Mode
X (change) UIM
ChromaZone Mode
(Yes) X (Back)
Channels per FIxture
UIM Channels per fixture.
X (change) UIM
(Yes) X (Back)
Channels per fixture
Fixture number
UIM Fixture number.
X (change) UIM
Fixture number
(Yes) X (Back)
chase patterns
UIM Chase patterns
X (change) UIM
chase pattern way number
(Yes) X (Back)
PORTABLE APPLIANCE TESTING -
STANDARDS -
The
may be safely Earth Bond and Insulation Tested.
The complies with the
following International and National Standards:
IEC65, EN60065, BS415
- EN50081-1, EN55022, EN50082-1
- IP20
Pulsar
ChromaZone
Pulsar ChromaZone
Electrical Safety -
EMC
Index of Protection
Marking Directive 93/68/EEC - The
meets both the EMC directive
2004/108/EC and the Low Voltage Directive
2006/95/EC.
Pulsar
ChromaZone
Depth
Weight
kgmm
70.0
67.0
2.0
1.0
CZ6-100C
CZ12-200
Code
Description
DIMENSIONS AND WEIGHTS
ChromaZone6-100 Compact
ChromaZone12-200 No CFlex
Width
Height
mmmm
170.0
98.0
320.0
250.0
CM
US
I
N
T
E
R
T
E
K
L
I
S
T
E
D
3048422
Conforms to:
UL 8750
UL 1598
GUARANTEE - three years from the date of original purchase.
The guarantee covers defects in manufacturing workmanship
and materials. It is limited to parts and labour. The guarantee
becomes void if the product is: a) misused, b) not used in
accordance with the instructions, c) the cable connections are not
made according to our instructions if the unit is used in damp or
wet environments, d) repairs are made by unauthorised persons,
e) the serial number label has been removed or defaced. Pulsar's
maximum liability shall not exceed the price paid for the product.
In the unlikely event of a fault occurring, do not use without repair.
Return the product, with a description of the fault, to your supplier
or direct to Pulsar for immediate attention.
108.0 2.0
CZ12-200IP
ChromaZone12-200 IP65
240.0 312.0
USER INTERFACE MODULE AND FUNCTIONSOTHER INFORMATION
