Pulsar FORWARD FN455S User Manual

ENGLISH
ENGLISH
Package Contents
•
Digital module
•
Pulsar 5x30 Monocular
•
Carrying Case
•
Wireless Remote Control
•
IPS7 Battery Pack
•
Battery Pack Charger
•
Power Adapter
•
USB Cable
•
Quick Start Guide
•
Lens-Cleaning Cloth
•
Warranty Card
Components and Controls
1. Lens cover
2. Eyepiece cover
3. Battery compartment cover
4. Battery locking lever
5. Battery pack
6. RIGHT button
7. M (MENU) button
8. LEFT button
9. ON button
10. Lens focus knob
11. IR illuminator cover
12. IR illuminator connector cap
13. Connector for installing IR illuminator
14. MicroUSB port
15. Weaver rail
16. Adapter cover*
17. Optical device lens
18. Insert*
19. Adapter*
20. Tightening screw*
21. Screw*
22. Adapter lever*
23. Mounting area
24. IR button
25. IR illuminator arm
26. IR illuminator lens lock knob
*Items of Cover Ring Adapter FN (available separately)
1

Pulsar FORWARD FN455S Specifications

General

Brand	Pulsar
Model	FORWARD FN455S
Category	Binoculars
Language	English
