ENGLISH
Charging Battery Pack
The device is supplied with a rechargeable IPS7 Lithium-ion Battery Pack which
allows the device to be used for up to 9 hours. Charge the battery before rst use.
29 32
27
28
5
31
30
•
Raise the lever (27) of the charger.
•
Insert the battery (5) into the charger as shown in the diagram and lower the
lever (27).
•
Attach the microUSB plug of the USB cable (30) to the microUSB connector
(29) on the charger.
•
Connect the USB plug on the cable (30) to the power adapter (31).
•
Plug the power adapter (31) into a 100-240V (32) socket.
•
When the indicator is continuously green, the battery is fully charged.
Disconnect the charger from the mains.
Installing the Battery Pack
•
Lower the lever (4)
•
Remove the protective cover of
the battery compartment (3).
•
Insert the battery (5) into the
slot designed for it on the device
body so that the element (D) is
pointing downwards
•
Lock the battery (4) in place by
raising the lever (4).
D
4
