4
DESCRIPTION OF PRODUCT PARTS
As shown in Fig 2
Carefully remove the machine from its packaging and check that the following parts are complete:
A. Main mower deck (with upper handle and lower handle) 1pc
B. Cable clip 2pc
C. Grass bag assembly
D. Side discharge chute 1pc
E. Manual 1pc
F. Big knob with bolt M6 2 pc
G. Small knob with bolt M6 2 pc
H. Spark Plug Wrench 1pc
I. Plastic mulching plug 1pc (inside the mower)
Fig 2
If any parts are damaged or missing, do not operate this tool until the missing parts are
replaced. Failure to heed this warning could result in serious personal injury.
WARNING!
This item requires a two person lift to remove from the packaging. Make sure that you have
sufficient space to put the lawn mower down. Keep your feet apart so that you have a stable
position, bend at the knees and keep your back straight.
WARNING!
NOTE! Always recycle the packaging in accordance with local recycling laws.
NOTE!
