Puqpress M2 - Personel Requirements; 2 Technical Data; 3 Description

5
EN
Precision coee tamper
1.2 Personnel requirements
No special requirements are necessary for the users of this tamper.
Nevertheless it is a prerequisite that these operating instructions
have been carefully read and understood and that all instructions
provided are observed. In addition, safety-conscious operation is
expected.
2 Technical data
Model number 2-000-01XX-2, 2-000-02XX-2,
2-000-03XX-2, 2-000-04XX-2,
2-000-05XX-2, 2-000-07XX-2
Voltage / Frequency 100-240 Vac
50-60 Hz
Power 76 W
Dimensions [mm] W 230, D 270 , H170
Weight 4.5 kg (10lbs)
Year built See tag plate top side
Tamper diameter See tag plate top side
3 Description
The main components and operating elements are pictured in the
illustration.
Pos. Part name
1 Top plate
