Pure Humidifier INTAC User Manual

23
INTAC
®
MENU
DISPLAY OPTIONS
MFG
DEFAULT DESCRIPTION
505
RH Process Lo RANGE: 0.0 to 20.00 mA 4.00 Low range in milliamps for signal on plug J2 terminal 2 and 3
RANGE: 0.00 to 10.00 VDC 0.00 Low range in Volts for signal on plug J2 terminal 1 and 3
506
RH Process Hi RANGE: 0.00 to 20.00 mA 20.00 High range in milliamps for signal on plug J2 terminal 2 and 3
RANGE: 0.0.0 to 10.0 VDC 10.00 High range in Volts for signal on plug J2 terminal 1 and 3
508
Hi-Limit Sensor None Option No High Limit input available (set with menu 707)
Current Option Used when a supply air high-limit humidity sensor is a mA current
type of signal on plug J4 terminal 6 and 7
Voltage Option Used when a supply air high-limit humidity sensor is a VDC type
of signal on plug J4 terminal 5 and 7
509
HL Process Lo RANGE: 0.00 to 20.00 mA 4.00 Low range in mA for humidity signal on plug J4 terminal 6 and 7
RANGE: 0.00 to 10.00 VDC 0.00 Low range in volts for signal on plug J4 terminal 5 and 7
510
HL Process Hi RANGE: 0.00 to 20.00 mA 20.00 High range in mA for humidity signal on plug J4 terminal 6 and 7
RANGE: 0.00 to 10.00 VDC 10.00 Low range in volts for humidity signal on plug J4 terminal 5 and 7
511
Air Sensor None Option No air temperature sensor input available (set with menu 704)
Current Option Current input for outside air temperature sensor
512
Air Process Lo RANGE: 2.00 to 20.00 mA 4.00 Low range in mA for outside air temp signal on plug J4 terminal 3
and 4
513
Air Process Hi RANGE: 2.00 to 20.00 mA 20.00 High range in mA for outside air temp signal on plug J4 terminal 3
and 4
514
Air Range Lo RANGE:-100° to +1000°C 0.0 Low range scale for outside air temperature sensor in °C
RANGE:-100° TO +1000°F -30 Low range scale for outside air temperature sensor in °F
515
Air Range Hi RANGE:-100° to +1000°C 55 High range scale for outside air temperature sensor in °C
RANGE:-100° TO +1000°F 130 High range scale for outside air temperature sensor in °F
516
Air Offset RANGE : 0° to +60°F 0 Offset to calibrate temperature sensor to outside air temp in
degrees Fahrenheit
RANGE: 0° to +33°C 0 Offset to calibrate temperature sensor to outside air temp in
degrees Celsius
517
Process Output Current
Output signal (mA DC) for device or actuator—INTAC
®
Plug J3 terminal 5 and 6
Voltage x
Output signal (VDC) for device or actuator—INTAC
®
Plug J3 terminal 4 and 6
518
Out Process Lo RANGE:0.00 to 8.00 mA 4.00 Process output signal—Low range in Milliamps
RANGE: 0.00 to 3.00 VDC 0.00 Process output signal—Low range in Volts
