24
519
Out Process Hi RANGE: 10.00 to 20.00 mA 20.00 Process output signal—High range in Milliamps
RANGE: 3.00 to 10.00
VDC
10.00 Process output signal—High range in Volts
520
Dedicated Input Not Used x Dedicated input turned off
Dedicated Event
INTAC
®
terminals J1-5, J1-6 OPEN; humidifier output shuts off
Hi Limit Open Used to display when supply air humidity is above the safety
high limit setpoint. Connect high limit to terminals J1-5, J1-6
Auto Drain Closed contact will start an auto drain
Pnl Lockout
INTAC
®
terminals J1-5, J1-6 CLOSED; all menus LOCKED
including menu 520
521
Temp Units Fahrenheit x All temperatures in all screens and menus are in °F
Celsius All temperatures in all screens and menus are in °C
522
Capacity Units Lbs/Hr x All capacities in all screens and menus are in lbs/hr
Kgs/Hr All capacities in all screens and menus are in kgs/hr
523
Unit Capacity RANGE: 2 to 9999 Varies Unit capacity in lbs/hr
RANGE: 2 to 9999 Varies Unit capacity in kgs/hr
525
Menu Access All Menus x No menus are blocked from changing configurations
100 & 200 Menus All menus VIEW ONLY except menus 100, 200, and 500
100 Menu
All menus VIEW ONLY except menus 100 and 500
No Menus All menus VIEW ONLY except menu 500
701
Control Type SCR Varies Solid state relay output offers the best modulating control
Steam Modulating VDC or mA DC output signal to operate valve
actuator
Gas For use with up to 3 gas burners
702
Active Heaters 1 Varies One active heater
(Factory option only)
2 Two active heaters
3 Three active heaters
4 Four active heaters
INTAC
®
MENU
DISPLAY
OPTIONS
MFG
DEFAULT
DESCRIPTION
To Next Page
