Pure Humidifier INTAC User Manual

25
705
Level Sensor Tri-Probe Varies Humidifier tank level controlled by electronic Tri-Probe
(Factory option only)
None No tank level control available
Float Humidifier tank level controlled by mechanical level controller
706
Drain Type Automatic Varies Humidifier tank drains automatically per menu 202 & 203
configurations
(Factory option only)
Manual Humidifier tank must be drained manually via hand valve
None No tank drain available
707
Hi-Limit Enable Off Option Modulating Hi-Limit sensor input OFF
(Factory option only)
On Modulating Hi-Limit sensor input ON (INTAC
®
plug J4 termi-
nals 5,6 and 7)
708
Clean Time Accum Time x Auto drain timer counts down when heater output is on
(Factory option only)
Elapsed Time Auto drain timer counts down always
On Demand INTAC
®
does not time auto drain. Auto drain can only be
started through the dedicated input when 520 = Auto Drain
709
Gas Burners RANGE: 1 to 3 Varies Number of burners used on humidifier
(Factory option only)
710
Low Fire Set Pt RANGE: 5 to 100 Varies % power at which burner #1 turns on
Factory option only)
711
Low Fire Hys RANGE: 1 to 99 3% % power below Low Fire Set Point at which burner #1 turns
(Factory option only)
712
Burner 2 Set Point RANGE: 5 to 100% Varies % power at which burner #2 turns on
(Factory option only)
713
Burner 2 Hys RANGE: 1 to 99% 3% % power below Burner #2 set point at which burner #2 turns
off
(Factory option only)
INTAC
®
MENU
DISPLAY OPTIONS
MFG
DEFAULT DESCRIPTION
703
Water Enable Off Option Water temperature sensor for cool down or water
pre-heating OFF
(Factory option only)
On Water temperature sensor for cool down or water
pre-heating ON
704
Air Enable Off Option Outside air temperature sensor for setback control OFF
(Factory option only)
On Outside air temperature sensor for setback control ON
