Pure Reliability SOLO 250 - DMX Control Channel Functions

solo 250 manual_last revision_en.doc
8/16
The SOLO 250 uses 10 DMX channels. They are listed in the following table.
CHANNEL DMX VALUE DESCRIPTION
0-33
Open/Clear (5-7: for 5 seconds) Soft reset – See Note
34-66 Gobo 1
67-99 Gobo 2
100-132 Gobo 3
133-165 Gobo 4
166-199 Gobo 5
200-232 Gobo 6
1
Gobo
233-255 Gobo 7
0-8 Stop
9-163
9-163 Rotate in clockwise direction step by step
163-9 Rotate in anti-clockwise direction step by step
164-205 Rotate in clockwise direction from slow to fast
206-213 Stop
2
Gobo rotation
214-255 Rotate in anti-clockwise direction from slow to fast
0-27 White
28-55 Colour 1
56-83 Colour 2
84-111 Colour 3
112-139 Colour 4
140-167 Colour 5
168-195 Colour 6
196-223 Colour 7
224-251 Colour 8
3
Colour
252-255 Colour 9
0-10 Black-out
11-195 Open gradually from black to full open (dimming)
196-251 Strobe adjust from slow to fast
4
Strobe/Shutter
252-255 Open
5 Pan 0-255 Pan movement from 0° to 370°
6 Tilt 0-255 Tilt movement from 0° to 265°
7 Focus 0-255 Stepless focus
0-31 Clear
32-48 Prism static
49-127 Prism rotate in anti-clockwise direction step by step
128-189 Prism rotate in anti-clockwise direction from slow to fast
190-193 Prism static
8
Prism
194-255 Prism rotate in clockwise direction from slow to fast
9 Pan 16BIT 0-255 16 Bit Pan resolution
10 Tilt 16BIT 0-255 16 Bit Tilt resolution
Note:
Soft Reset – If the DMX value sent on this channel (1) stays in the range from 5 to 7 for more than 5
seconds, the projector will start a reset sequence (Remote Requested Reset). The electronics are re-
started and all motors moved to their home positions exactly as they do when the power is first
switched on but the lamp is not switched off in this sequence, although the beam will be blacked out.
The channels 9 and 10 are only available when the Setup Option 6 is “ON”.
When Setup Option 2 is “ON”, Pan movement is in anti-clockwise direction.
When Setup Option 1 is “ON”, Tilt movement is in anti-clockwise direction.
For the exact setting please refer to “Setup Options” section.
DMX CONTROL CHANNEL FUNCTIONS
