Purelogic PLD880

Edition from 23.11.2017
3
PLD880. Stepper motor driver
www.purelogic.ru8 (800) 555 63 74
01
02
General information
Delivery set
Technical features
PLD880 is an available microstepping stepper motor driver.
The driver has inbuilt coil short-circuit protection, back EMF effect
protection, inbuilt automatic compensator of normal speed stepper
motor resonance, phase current change scheme with frequency
increase, polarity reversal power protection, soft starter scheme; STEP
inbuilt frequency generator.
The device works with standard control protocol STEP/DIR/ENABLE.
The module has discrete regulation of operating current of stepper
motor phases. All driver’s control inputs are optoisolated and logic
levels 2.5V, 3.3V, 5V compatible.
The driver is AUTO-SLEEP mode supplied which is turned on when
there is no STEP signal.
The device is optimal for control of bipolar and unipolar Purelogic R&D
stepper motors(PL86 series). Work with other stepper motors is also
possible.
• Stepper motor driver PLD880 — 1 pcs.
• Instruction manual — 1 pcs.
03
01. General information
Stepdivision (microstep)
Unit weight without packaging
STEP Max signal frequency
Module power supply
Isolation resistance
Operating current of stepper motor driver
Operating temperature
STEP inbuilt generator frequency
Max shaft rotation frequency
600…3`000 Hz
42 cycles per second or 2530 cycles
per minute (PL86H113, 75V, step division
1:32, 270 kHz)
1:2, 1:4, 1:8, 1:16, 1:32
0,6 kg
270 kHz
18...80V (bogey value 75V)
500 MOhm
2,3...8A fig. 2 (discrete adjustment)
0...60 °С
!
Check www.purelogic.ru for more information.
Power off device before making any connections and mode operation
changing.
Do not mount the power switch after the power source (on the driver
power line). Power switch should be installed before power supply, at
~220v side.
Do not connect the drivers in series, only ‘star’ connection is allowed.
Do not connect power supply’s «-» to ground, mass, housing, etc.
Strictly observe the polarity of power supply and control signals
connections.
