21
2
KING INSTALLATION GUIDE
Secue hinge with shot bolt
Insert a short bolt through the rst hole
in the hinge of the frame.
Secure the end of the short bolt with
a washer and a nut.
Tighten the bolts with the box wrenches
provided.
A
B
C
Purple has partnered with Ergomotion
®
on this amazing product.
For technical or warranty support please contact Ergomotion
®
at
1-888-550-3746.
