Purple Ascent Adjustable Base - Securing King Base Hinges (Long Bolt)

22
3
KING INSTALLATION GUIDE
Insert a long bolt through the second
hole in the middle of the hinge of the
frame.
Secure the end of the long bolt with a
washer and a nut.
Tighten the bolts with the box wrenches
provided.
A
B
C
Secue hinge with long bolt
short bolt
long bolt
