Purple Premium Plus - Connecting Straps

14
With the bases in thei desied location, slightly loosen both legs to
allow the stap to t on the leg bolt, between the leg and fame.
Slide side (a) of the connecting stap onto leg bolt. Swing the stap
and connect side (b) to the leg bolt. Secue the stap by shifting to
the left.
Re-tighten legs. Do not ove tighten. Use the emaining stap and
epeat on othe end of the base.
STEP 2
STEP 1
STEP 3
Connecting Staps (Split Base Set Up Only)
If any split setup is being installed, plastic connecting straps are provided (one per base) to secure the bases to-
gether. Use both straps to secure the head and foot portions together.
a
b
