Pyle PLMRA620 Manual

general features
· 100 Watts x 4 Output.
+
250 Watts x 2 Output.
· 250 W x 4.
+
500 W x 2 Bridged Output ( 400 W x 2 + 900 W x 1)
· Variable Hi/Lo Electronic Crossover Network ( CH1/CH2/ and CH3/CH4)
· Variable Bass Boost (0 - +18 dB @ 60Hz) ( CH5/CH6)
· Variable Input Level (Gain) Control
· Low and High Pass Filter Controls( CH3/CH4)
· Remote Turn On/Off
· Gold Plated RCA Inputs
· Power ON LED Indicator
· LED Protection Indicator
· S/N Ratio: > 95 dB
· THD: <0.04%
· Thermal Protection
· Overload Protection
· Short Circuit Protection
· Anti-Thump Turn-On
· Blue LED Level Display
PLMRA620
High Performance 2000 Watt 6 Channel
Bridgeable MOSFET Amplifier
features and specifications
PLMRA620
6 ch amp PLMRA620

Pyle PLMRA620 Specifications

General

Bass boost	0 - 18 dB
Amplifier class	D
Frequency range	15 - 30000 Hz
RMS rated power	2000 W
Input sensitivity	250 mV
Built-in crossover	Yes
Audio input channels	5.1 channels
Peak power per channel	500 W
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.04 %
RMS power output per channel (2 Ohm)	400 W
RMS power output per channel (4 Ohm)	250 W
Bridge-mode power output per channel (4 Ohm)	900 W
XLR in	No
Audio (L/R) in	3
Speaker selector	A+B
USB 2.0 ports quantity	0
Speakers connectivity type	Clamp terminals
Purpose	Car
Material	Aluminum
Cooling type	Active
Product color	Blue, Silver
Volume control	Digital
Connectivity technology	Wired
Maximum current	60 A
DC input voltage	12 V
Power protection features	Overheating, Overload, Short circuit
LED indicators	Power, Status

Weight and Dimensions

Depth	498 mm
Width	276 mm
Height	69.5 mm
