19P1FL0801
11 / 12
Definition of RJ45 Port Pin
CAN
RS485
RS232
---
---
---
---
---
---
---
---
TX
CANH
---
---
CANL
---
---
GND
RX
---
RS485A
---
---
RS485B
---
Note: Other Pin must be NULL, if not may influence the communication of system.
