4
2.3 LED Indicators Instructions
Status
●
Only the HUB is turned ON, it lights once.
●
No battery connected or at least one group is off line. When
battery group is reduced it will alarm (in red), but when
battery group is added in it will no alarm.
1 2 3 4 Green flash; connected battery groups number
● 1 group
● 2 groups
● ● 3 groups
● 4 groups
● ● 5 groups
● ● 6 groups
● ● ● 7 groups
