AUTO ALIGNING TIME CLOCK INSTRUCTIONS
Model 2650
7pyramidtimesystems.com SET UP COLUMN SHIFT
The 2650 is pre-programmed in the MANUAL punch setting (default setting). In this set-
ting, the user manually chooses which column to punch by selecting the corresponding
button (1-6). Alternatively, the 2650 allows you to program the clock to automatically
“shift” to a specic column at a pre-set time (AUTO), or if preferred, the user may
override the automatic setting, and switch back to a manual setting at any time
(AUTO/MANUAL).
In the ADVANCED MENU = N menu, press s(UP) to choose “YES”.
Use SELECT button to scroll through Advanced Menu options until COL SHIFT = MAN
menu is displayed.
In the COL SHIFT = MAN menu, press s(UP) to choose “AUTO/MANUAL” or
“MANUAL”.
Press SELECT.
In the COL SHIFT SET = N menu, press s(UP) to choose “YES”.
Press SELECT.
In the COL 1 SETUP = N menu, press SELECT if no time setting is desired for column
1, or to assign a time to begin punches in column 1, press s(UP) to choose “YES”.
Press SELECT.
In the COL 1 HOUR = OFF menu, press s(UP) to select “HOUR”. Press s(UP) or
t(DOWN) to scroll to desired hour.
Press SELECT.
In the COL 1 MINUTE = 0 menu, press s(UP) or t(DOWN) to scroll to desired minute.
Press SELECT.
Repeat steps 7-12 for columns 2-6.
6
2
7
3
8
4
11
9
10
5
1
12
13
Column time must be assigned when using “AUTO SET”.
SET UP AUTO OR AUTO/MANUAL COLUMN SHIFT
