Tilt Detection
4°
When movement is detected, it is then analysed by the unit and if the
movement threshold angle is exceeded, an alarm will be generated.
Tilt or movement more than ~4° on the x or y axis from the “home
position” will constitute as movement.
Please note: The degree of angle given to constitute movement is an approximation.
Detection Mode Check
If the button is pressed and held for 3 seconds, the LEDs will indicate what the detection mode is
set to.
Please note: In order for detection mode to work, the LEDs must be activated.
Back to Home (B2H)
If the button is pressed for 1 second and released, the device polls the panel to check whether the
device is in range of the system.
This is the only function relating to the LEDs that will still function after the 1 hour timer has expired.
Blue flash then green
Indicates the device is within range of the system and
has good signal strength.
Blue flash then red
Indicates the device is within range of the system but
has bad signal strength.
Blue flash only
The device has polled the system but has not had a
response therefore it is out of range.
HOME POSITION
The “Home Position” is the installation position of the device. Once a “Home Position” has
been determined by the device, if the device is triggered, it will signal to the system it has been
triggered.
The device will calibrate its “Home Position” after the following scenarios:
• After a period of 4 seconds once the case is closed.
• After a period of 10 seconds following an alarm activation.
The device can be relocated wherever the user sees fit when the system is disarmed (providing the
zone is not programmed as 24 hour or day alarm).
