Enforcer 32-WE Wireless Setup Manual
Page: 19
9.3.3 Magnet Detection Performance
9.3.4 Technical Specification
Battery:
Type: 3.0V CR123A Lithium Battery. Threshold: 2.5V +/- 5% at 25°C. Life: Up to 2 Years
Wireless:
Transmission Frequency: 868MHz, FM Transceiver Narrow Band
Transmission Method: Fully encrypted rolling code
Materials and Environment
Colour and Casing: White. 2mm ABS
Indication: LEDs (Signal, Alarm, Tamper). GREEN=MC. RED=SHOCK.
Temperature: Storage:-20°C to 50°C. Certified:-10°C to 40°C. Nominal:-10°C to 50°C
Dimensions (H x W x D): 30 x 115 x 35mm. Magnet: 17 x 56 x 12.7mm
Compatible with the Enforcer 32-WE, PCX and EURO control panels (Enforcer 32-WE wireless
expander only).
Front and rear tamper. 1 external input & 1 external tamper input (normally closed).
NOTE: The use of external inputs will make the system unable to comply with EN50131-1.
Spacers available if required: MC1S/SPACER-WE and MC1S/SPACERB-WE.
26mm
24mm
23mm
20mm
24mm
22mm
14mm
14mm
13mm
13mm
22mm
20mm
19mm
17mm
11mm
9mm
13mm
13mm
12mm
12mm
