Pytes E-BOX-4850 - 3 Operating Environment

Pytes E-BOX SERIES LFP Battery User Manual
10
3
Soft start switches
SW
Press and hold this button for 1
second while the switch key is "ON"
to enter Start or Sleep mode
4
DIP switch
ADD
Select the matching manufacturer,
see the match list (appendix C)
5
Running light
RUN
Green light. The light flashes when
Standby. The light is constantly on
when charging. The light flashes
when discharging.
Alarm indicator
ALM
Red light. The light flashes when
Alarming. The light is continuously on
when protected.
Capacity indicator
CHARGE
A total of 6 green lights showing
battery capacity, each representing
16.7% of SOC.
6
External CAN
communication port
CAN
Communication with external devices
7
External RS-485
communication port
RS485
Communication with external devices
8
Cascade terminal
Link Port
The master is connected to PORT1,
and the slave is connected to
PORT0.
9
Input and output
interface (negative)
“-“
Negative input and output interface
10
Input and output
interface (positive)
“+“
Positive input and output interface
Warning: 6,7,8,9,10 is DVC-A circuit, they shall not be connected to DVC-B/C
circuit when installed, or hazard shock will occur.
