37
Calibration of the Z-axis (QL320HV/HVV):
For the calibration of the Z-axis we recommend to use a calibrated optical
level. Use the horizon of the level in order to calibrate the plumb beam in
vertical mode. Ask your authorised dealer for this procedure if necessary.
To calibrate the height of the laser beam follow the instruction as written
before, just in vertical use. The X and Y LED’s are lit to indicate the Z axis
calibration mode. Move the height of the laser beam with the up and down
arrow keys. Storing and cancelling of the calibration is working as in
horizontal mode.
Error indication during the calibration.
The range of the electronic calibration is marked. If the range will be
exceeded, the X or Y led flashes.
Please make sure that the calibration process was kept correctly. If the laser
can not be calibrated to the correct horizon, it may need mechanical
adjustment. In this case please contact your next service dealer or the QBL
Baulaser GmbH.
Error table
Error Description Countermeasure
All LEDs are flashing
after turn on. Instrument
turns off automatically
after app. 15 seconds.
The calibration values
are not valid. This may
happen if e.g. the
batteries are removed
during calibration
process.
Press the on button
again while the LEDs are
flashing. Start the
calibration mode within
15 seconds. Calibrate
the instrument again.
Instrument will not turn
on.
Batteries flat,
No contact to the battery
chamber, battery
contacts defective (e.g.
cause of water inside).
Replace batteries, if
necessary replace
battery chamber.
No charge function
(LED will not lit)
Charger defective Replace charger
Charging interrupted
(LED turns off).
No or bad connection in
accumulator chamber,
High temperature,
wrong rechargeable
battery
Check accumulator
chamber, replace if
necessary. Locate
instrument in cool place,
place correct battery type
