BWT20 Qilin double swing handheld laser
8
7/24
2.2 Structural diagram of gun and pipe and water pipe
interface
Figure 2.21, a structural diagram of the gun
=
parameter scope
interface type QBH
laser power 2000W
Collar focal length 50
Focus focal length 150
Regulate the spot Points, line, circle, ellipse,
triangle, 8 words, semicircle
Adjustable surface 0—5mm
cooling-down method Water cooling / air cooling
Applicable wavelength 1064-1080nm
Collimine lens D20F50
Focus on the lens D20F150
Reflective mirror 22.5×17T3
Protection mirror specifications D20T2
Maximum air pressure support 0.6Mpa
