Qilin Laser Application Technology BWT20 - Gas and Water Pipe Interface

BWT20 Qilin double swing handheld laser
welding
system
user
manual
V1.0
9
7/24
Focus of vertical adjustment
range
±3mm
TBM 0.98KG
Figure 2.22 Schematic diagram of gas pipe and water pipe interface
Water pipe: a water pipe in and out, forming a closed water cycle.
Tracheal: single connector, gas output.
DB15 interface: connect the control system and the gun head communication function.
Samsung Air plug: Connect the conduction and trigger signal connector.
