Qilin Laser Application Technology BWT20 - Power Interface Specifications

BWT20 Qilin double swing handheld laser
welding
system
user
manual
V1.0
10
7/24
2.3 Power interface
Figure 2.31 Schematic diagram of the Power interface
+ 15V interface is the interface that provides power for the motor drive inside
the control box, the voltage is positive or minus 15V (+ 15V),
Table 2.31 defines the
definition of + 15V interface
Table 2.31
pin signal defi
niti
on
expl
ain
1 V1
Power supply input is
positive at 15V
+ 15 External power input,
external power output
The current is
greater than 2A
2 COM Power reference
Power to
