Qlight SESA - Ordering Specifications; Product Specifications

2
Model number
SESA
SESAL
SESALR
SESAS
Range of
operating
voltage
DC 24V
AC120V or 230V
Ex mark
IECEx - Ex db IIC T6 Gb, IP66
ATEX - II 2G Ex db IIC T6 Gb,
IP66
NEPSI, CCC - Ex db IIC T6 Gb,
Ex tb IIIC 80°C Db
KCs - Ex d IIB+H2 IP66 T6(SESA)
Ex d IIC T6 IP66,
Ex tD A21 T85°C IP66(SESAKC)
TS - Ex db IIC T6 IP66 Gb(SESAL)
Ambient
operating
temperature
-20°C ≤ Tamb ≤ +60°C(TS)
-40°C ≤ Tamb ≤ +55°C(KCs)
-40°C ≤ Tamb ≤ +60°C
Explosion proof
Zone
Zone1, Zone2, Zone21, Zone22
Protection
rating
IP66
Model
number
Voltage Current
Bulb specications
Sound pattern and volume
Certicate
Weight
Color
Volts/
Watts
Conguration Part#
SESA
DC24V 1.788A 24V15W G23 15S 18
• WS-5 Warning sounds
: Max.118dB
• WP-5 Special warning
sounds: Max.118dB
• WM-5 Melodies: Max.118dB
• WA-5 Alarms: Max.116dB
• WV-5 Customizable voices
: 110-115dB
8.57kg
R-Red
A-Amber
G-Green
B-Blue
AC120V 0.422A 12V15W G23 15S 17 9.27kg
AC230V 0.211A 12V15W G23 15S 17 9.27kg
SESAS
DC24V 1.411A
200V
-550V
EUB0641
-1A(G)
U type
48
8.45kg
AC120V 0.360A 8.86kg
AC230V 0.220A 8.86kg
Model
number
Voltage Current Sound pattern and volume
Certicate
Weight
Color
SESAL
DC24V 1.222A
• WS-5 Warning sounds
: Max.118dB
• WP-5 Special warning
sounds: Max.118dB
• WM-5 Melodies: Max.118dB
• WA-5 Alarms: Max.116dB
• WV-5 Customizable voices
: 110-115dB
8.42kg
R-Red
A-Amber
G-Green
B-Blue
AC120V 0.286A 9.02kg
AC230V 0.143 A 9.02kg
SESALR
DC24V 1.288A 8.31kg
AC120V 0.308A 7.92kg
AC230V 0.154A 7.92kg
Product Specications
Zone
denitions(Gas)
Zone 1 High risk gas/vapour
Zone 2
Medium risk gas/vapour
Group
denitions(Gas)
GROUP II A
Acetone, Petrol, Methanol, Propane, Toluene
GROUP II B Ethylene, City gas
GROUP II C Hydrogen, Acetylene, Carbon sulphide
Maximum
surface
temperature
of electrical
equipment
T1 450 °C
T2 300°C
T3 200°C
T4 135 °C
T5 100 °C
T6 85 °C
Zone
denitions(Dust)
Zone 21 High risk powder/dust
Zone 22 Medium risk powder/dust
Group
denitions(Dust)
GROUP II A Ignitible bers/yings(mzore than 0.5mm)
GROUP II B Non-conductive dusts
GROUP II C Conductive dusts
■
Explosion Proof Specications
■
General Product Specication
Ordering Specications
SESAS
-
WS
-
230
-
R
[Model number] [Sound] [Voltage] [Color]
| | | |
• SESA
• SESAS
• SESAL
• SESALR
• WS-Warning sounds
• WP-Special warning sounds
• WM-Melodies
• WA-Alarms
• WV-Customizable sounds
• 24-DC24V
• 120-AC110V
• 230-AC220V
R-Red
A-Amber
G-Green
B-Blue
※
Voltage AC120V: AC110V-120V, AC230V: AC220V-230V
※
CCC(F) compliant: DC24V(SESAL)
