Fig. 18
Fitting the drain hose and holder
To drain the condensation from the lower water tank, a hose and holder are supplied
with the air conditioner.
1
Remove the rubber plug (see fig. 19).
Fig. 19
2
Connect the supplied hose J (see fig. 1) to where the rubber plug was (see fig.
20) and fasten the hose with hose clip I.
Fig. 20
3
Fit the hose holder G (see fig. 1) to the rear of the air conditioner (see fig. 21).
Fig. 21
4
If the hose is not being used to drain the condensation, place the hose in the
hose holder to prevent leaks (see fig. 22).
4
