Qlima P528 User Manual

4
53
2
Assembly:
Slide Panel Band C into Panel A and size to widow width. Windows sizes
vary. When sizing the window width, be sure that the window kit assembly is
free from gaps from gaps and/or air pockets when taking measurements.
3
Lock the screw into the holes that correspond With the width that your
window requires to ensure that there are no gaps or air pockets in the
window kit assembly after installation.
D DESCRIPTION OF THE DISPLAY SCREEN
1. COOL symbol
2. HEAT symbol*
3. FAN Speed indicator
4. TIMER symbol
5. Temperature symbol
6. Temperature indicator
* means only the heat pump model have this function.
OPERATING FROM THE CONTROL PANEL
The control panel is on the top of the appliance, enables you to manage part
functions without remote controller, but to fully exploit its potential, you
must use the remote controller.
1 ON/OFF button
2 MODE button
3 FAN button
4 INCREASE button
5 DECREASE button
TURNING THE APPLIANCE ON
Plug into the mains socket, then the appliance is standby. Press the
button
to make the appliance turn on. The last function active when it was turned
off will appear.

Qlima P528 Specifications

General

AC input voltage	220-240 V
AC input frequency	50 Hz
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	No
Hourly energy consumption (cooling)	1.1 kWh
Hourly energy consumption (heating)	- kWh
Type	Monobloc mobile air conditioner
Noise level	65 dB
Number of speeds	3
Airflow (high speed)	330 m³/h
Refrigerating medium	R410A
Adjustable thermostat	Yes
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.1 l/h
Air conditioner functions	Cooling, Dehumidifying
Cooling temperature range	18 - 32 °C
Refrigerating medium weight	580 g
Suitable for room volume up to	90 m³
Cooling capacity in watts (max)	2800 W
Heating capacity in watts (max)	- W
Cooling energy efficiency (EER, W/W)	2.62
Heating energy efficiency (COP, W/W)	-
Product color	White

Weight and Dimensions

Depth	715 mm
Width	435 mm
Height	350 mm
Weight	29000 g
Package depth	845 mm
Package width	479 mm
Package height	389 mm
Package weight	33000 g
