Qlima P528 User Manual

SELF-DIAGNOSIS
The appliance has a self diagnosis system to identify a number of malfunctions.
Error messages are displayed on the appliance display.
IF IS DISPLAYED WHAT SHOULD I DO?
LOW TEMPERATURE
(frost prevention)
The appliance is fitted with a frost protection device
to avoid excessive formation of ice.
The appliance starts up again automatically when
the defrosting process is completed.
PROBE FAILURE
(sensor damaged)
If this is displayed, contact your local authorised
service centre.
FULL TANK
(safety tank full)
Empty the internal safety tank, following the
instructions in the “End of season operations”
paragraph.
E MANUAL OF REMOTE CONTROL
4.7
Fan button
Swing button
Sleep button
Increase button
Decrease button
On/Off button
Mode button
Timer button
Unit Switch button
Point the remote control at the receiver on the appliance.
The remote control must be no more than 7 meters away from the
appliance (without obstacles between the remote control and the receiver).
The remote control must be handled with extreme care. Do not drop it or
expose it to direct sunlight or sources of heat. If the remote control do not
work, please try to take out the battery, and put it back.
Max. 7 meters
Insulating strip Remove
SETTING THE TIMER
This timer can be used to delay the appliance startup or shutdown, this avoids wasting
electricity by optimising operating periods.
4
56

Qlima P528 Specifications

General

AC input voltage	220-240 V
AC input frequency	50 Hz
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	No
Hourly energy consumption (cooling)	1.1 kWh
Hourly energy consumption (heating)	- kWh
Type	Monobloc mobile air conditioner
Noise level	65 dB
Number of speeds	3
Airflow (high speed)	330 m³/h
Refrigerating medium	R410A
Adjustable thermostat	Yes
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.1 l/h
Air conditioner functions	Cooling, Dehumidifying
Cooling temperature range	18 - 32 °C
Refrigerating medium weight	580 g
Suitable for room volume up to	90 m³
Cooling capacity in watts (max)	2800 W
Heating capacity in watts (max)	- W
Cooling energy efficiency (EER, W/W)	2.62
Heating energy efficiency (COP, W/W)	-
Product color	White

Weight and Dimensions

Depth	715 mm
Width	435 mm
Height	350 mm
Weight	29000 g
Package depth	845 mm
Package width	479 mm
Package height	389 mm
Package weight	33000 g
