1Rearshockabsorberassembly
springpreloadadjustingring
2Sparkarrester
3Storageboxandtoolkit
4Spakplug
5Frontshockabsorberasembly
springpreloadadjustingring
6Brakepedal
7V-beltcase
8uelcock
9Airfiltercase
Fuses
Tail/brakelight
r
s
F
NOTE:
Themachineyouhavepurchasedmaydifferslightlyfromthoseshowninthe
figuresofthismanual.
DESCRIPTIONANDMACHINIDENTIFICATION
11
12FrontShockabsorberassembly
SpringPreloadadjustingRing
13V-beltcoolingductcheckhose
14OilFiltercartridge
15Engineoildipstick
16Rearbrakelever
17Lefthandlebarswitches
18Starter(choke)
19Driveselectlever
20Mainswitch
21Fueltankcap
22Righthandlebarswitch
23Throttlelever
24Frontbrakelever
10
11
