5 – Managing Ports
Port Statistics Data Window
59264-02 A 5-9
A
LongFrameCount Number of incidents when one or more frames are received
that are greater than the maximum size (2136 bytes).
Loop Timeouts Number of loop timeouts.
Loss Of Sync Number of synchronization losses (>100 ms) detected by this
port. A loss of synchronization is detected by receipt of an
invalid transmission word.
Primitive Sequence
Errors
Number of bad primitives received by the port.
Rx Link Resets Number of link reset primitives received from an attached
device.
Rx Offline Sequences Number of offline sequence primitives received by the port.
ShortFrameCount Number of incidents when one or more frames are received
that are less than the minimum size (24 bytes).
Total Errors Total number of primitive and non-primitive port link errors.
Total Link Resets Number of link-reset primitives transmitted and received by the
port.
Total LIPs Received Number of loop initialization primitive frames received.
Total LIPs Transmitted Number of loop initialization primitive frames transmitted.
Tx Offline Sequences Number of offline primitives transmitted by the port.
Total Rx Frames Total number of frames received by the port.
Total Rx Words Total number of words received by the port.
Total Tx Frames Total number of frames transmitted by the port.
Total Tx Words Total number of words transmitted by the port.
Tx Link Resets Number of link reset primitives sent from this port to an
attached port.
TotalTXErrors Total number of errors transmitted by the port.
TotalRXErrors Total number of errors received by the port.
Total Offline
Sequences
Total number of offline sequences transmitted and received by
the port.
Table 5-2. Port Statistics Data Window Entries (Continued)
Entry Description
