QMTECH XILINX SPARTAN-7 - Getting Started; Install Development Tools

QM_Spartan-7 Development Board User Manual V01
2. Getting Started
Below image shows the dimension of the QM_Spartan-7 development board: 6.6cm x 5.7cm. The unit in
below image is millimeter(mm).
Figure 2-1. QM_Spartan-7 Development Board Dimension
2.1 Install Development Tools
The QM_Spartan-7 development board tool chain consists of Xilinx Vivado 2018.2, Xilinx USB platform cable,
Mini USB cable for power supply. Below image shows the Xilinx Vivado 2018.2 development environment
which could be downloaded from Xilinx office website:
Figure 2-2. Vivado 2018.2
